QSFP-100G-SR4-IQSFP28

$380.00

The Cisco QSFP-100G-SR4-I Compatible QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 100m over OM4 multimode fiber (MMF) using a wavelength of 850nm via an MTP/MPO-12 connector. This transceiver is compliant with IEEE 802.3bm 100GBASE-SR4 and CAUI-4 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core, distribution layer and telecom applications.

The Cisco QSFP-100G-SR4-I Compatible QSFP28 Optical Transceiver Module is designed for use in 100GBASE Ethernet throughput up to 100m over OM4 multimode fiber (MMF) using a wavelength of 850nm via an MTP/MPO-12 connector. This transceiver is compliant with IEEE 802.3bm 100GBASE-SR4 and CAUI-4 standard. Digital diagnostics functions are also available via the I2C interface, as specified by the QSFP28 MSA, to allow access to real-time operating parameters. With these features, this easy to install, hot swappable transceiver is suitable to be used in various applications, such as data centers, high-performance computing networks, enterprise core, distribution layer and telecom applications.

Cisco QSFP-100G-SR4-I Compatible 100GBASE-SR4 QSFP28 Optical Transceiver Module (Industrial, MMF, 850nm, 100m, MTP/MPO, DOM)

Product Highlights

Max. Power Consumption 1.8W
Tested in Targeted Switches for Superior Performance, Quality, and Reliability
High-Speed Electrical Interface Compliant to IEEE 802.3bm
Support 100G to 4x25G Breakout Application
Industrial Temperature Range -40°C to 85°C
FS BOX - Support Real-time Configuration
Hot Pluggable QSFP28 MSA Compliant
Class 1 FDA Laser Safety and RoHS Compliant
Digital Optical Monitoring Capability for Strong Diagnostic Capabilities

KeyValueKeyValue
Part NumberQSFP-100G-SR4-IVendor NameFS
Form FactorQSFP28Max Data Rate103.125Gbps (4x 25.78Gbps)
Wavelength850nmMax Cable Distance70m@OM3/100m@OM4
ConnectorMTP/MPO-12MediaMMF
Transmitter TypeVCSEL 850nmReceiver TypePIN
TX Power-8.4~2.4dBmMinimum Receiver Power-10.3dBm
Powerbudget1.9dBReceiver Overload2.4dBm
Typical Power Consumption≤1.8WExtinction Ratio＞3dB
DDM/DOMSupportedIndustrial Temperature Range-40 to 85°C (-40 to 185°F)
CDR (Clock and Data Recovery)TX & RX Built-in CDRInbuilt FECNo
ProtocolsIEEE 802.3bm - QSFP28 MSA - SFF-8665 - SFF-8636 - RoHS - CPRI - eCPRIWarranty5 Years
